KLARK TEKNIK RPDN330 GRAPHIC 1/3 OCTAVE EQUALIZER - PRICE INCLUDES PLATINUM MEMBERSHIPS
[PRICED PER UNIT - 4 AVAILABLE AT TIME OF LISTING]
Listing last update on December 08, 2006 - Viewed 73 times

BUY THIS AT OUR ASKING PRICE AND WE WIL TAKE $125 OF THE TOTAL PRICE AND PUT IT TOWARDS YOU PLATINUM MEMBERSHIP OR IN OTHER WORDS A FREE PLATINUM MEMBERSHIP WITH THIS PURCHASE.

KLARK TEKNIK DN330 SINGLE CHANNEL, 30 BAND 1/3 OCTAVE GRAPHIC EQUALIZER OFFERING 12DB OF CUT OR BOOST IN 1/3 OCTAVE STEPS BETWEEN THE FREQUENCIES OF 20HZ AND 20KHZ. PRICE INCLUDES PLATINUM MEMBERSHIP. LIKE NEW IN FACTORY PACKAGING, HAS NOT BEEN USED SINCE BEING 100% FACTORY REFURBISHED BY KT.

CLICK HERE FOR THE SPEC SHEET

THE KLARK TEKNIK DN330 IS A SINGLE CHANNEL, 30 BAND EQUALISER OFFERING 12DB OF CUT OR BOOST IN 1/3 OCTAVE STEPS BETWEEN THE FREQUENCIES OF 20HZ AND 20KHZ. FILTER SHAPE AND COMBINING ACTION. AT THE HEART OF ANY EQUALISER IS THE BANK OF FILTERS USED TO SHAPE THE SIGNAL RESPONSE, AND KLARK TEKNIK UTILISE A PROPRIETARY FILTER CIRCUIT WHICH REPLACES WHICH REPLACES THE CONVENTIONAL INDUCTOR BASED CIRCUIT, AT THE SAME TIME, OFFERING SEVERAL PERFORMANCE ADVANTAGES. INDUCTOR BASED CIRCUITS ARE HEAVY, EXPENSIVE TO PRODUCE AND SUFFER FROM LOW FREQUENCY DISTORTION AND INDUCED HUM. KLARK TEKNIKæ‹… PROPRIETARY FILTERS ON THE CONTRARY SUFFER NONE OF THESE PROBLEMS, YET OFFER UNEQUALLED PHASE RESPONSE AND CONTROL ACCURACY WITH THE ADDITIONAL BENEFITS OF LOW NOISE AND MINIMAL RIPPLE.

THE NATURE, SHAPE AND WAY IN WHICH INDIVIDUAL EQUALISER FILTERS COMBINE, HAS A PROFOUND EFFECT ON THE CONTROL PROVIDED BY THE EQUALISER AND ON THE RESULTING QUALITY OF SOUND. THE MAJORITY OF APPLICATIONS WITHIN THE SOUND REINFORCEMENT, BROADCAST AND RECORDING FIELDS, REQUIRE A SMOOTH AND CONTINUOUS EQUALISATION RESPONSE CURVE IN ORDER TO CORRECTLY CONTOUR THE OVERALL RESPONSE CHARACTERISTICS OF A SOUND SYSTEM, LOUDSPEAKER, RECORDING EFFECT OR AUDIO CHANNEL. TO ACHIEVE THIS, THE INDIVIDUAL FILTERS MUST BE CAPABLE OF COMBINING SMOOTHLY TOGETHER TO RESULT IN A CONTINUOUS RESPONSE CURVE, FREE FROM SHAPE DISCONTINUITIES IN ORDER TO AVOID UNWANTED AUDIBLE PEAKS OF ANOMALIES IN THE FINAL SOUND. INDIVIDUAL CHANNEL LEVEL CONTROLS, OVERLOAD INDICATORS AND BYPASS SWITCHES WITH INCORPORATED LOW CUT FILTERS ARE FEATURED ON THE CONTROL PANEL.

OTHER FEATURES:

THE BYPASS SWITCH SILENTLY REMOVES THE GRAPHIC EQUALISER SECTIONS FROM THE SIGNAL PATH. THE EQUALISER ALSO INCORPORATES VARIABLE LOW AND HIGH PASS 12DB/OCTAVE FILTERS WITH A RANGE FROM 2K5HZ TO 30KHZ AND 15HZ TO 300HZ RESPECTIVELY. OTHER FEATURES INCLUDE AN OVERLOAD LED PER CHANNEL, WHICH WARNS OF IMPENDING OVERLOAD AT ANY POINT IN THE EQUALISER. A DETACHABLE SECURITY COVER IS AN INHERENT FEATURE TO PREVENT UNAUTHORISED PERSONNEL FROM TAMPERING WITH THE CONTROL SETTINGS. THIS PRODUCT IS BUILT TO THE SAME HIGH ELECTRICAL AND MECHANICAL STANDARDS AS ALL KLARK TEKNIK EQUIPMENT AND IS BOTH ROBUST AND STYLISH. IT OCCUPIES A STANDARD ONE UNIT OF RACK SPACE AND HAS ELECTRONICALLY BALANCED INPUTS AND OUTPUTS.

LIKE NEW IN ORIGINAL FACTORY REPACKAGING, 100% REFURBISHED, DISCONTINUED BY FACTORY, FOB NV, FOR DETAILS SEE HTTP://WWW.KLARKTEKNIK.COM/PAGES/SET_SUPPORT.HTML

TECHNICAL SPECIFICATIONS INPUT ONE TYPE ELECTRONICALLY BALANCED IMPEDANCE BALANCED 20KOHMS UNBALANCED 10KOHMS MAX INPUT LEVEL 20DBM OUTPUT ONE TYPE ELECTRONICALLY BALANCED SOURCE IMPEDANCE 50 OHMS MIN.LOAD IMPEDANCE 600 OHMS MAX.LEVEL 20DBU WITH 2KOHM LOAD PERFORMANCE FREQUENCY RESPONSE 20HZ TO 20KHZ, EQ FLAT +/-0.5DB THD+N @ +4DB <0.01% @ 1KHZ EQUIVALENT INPUT NOISE (20HZ TO 20KHZ UNWEIGHTED) <-86DBU GAIN -6 TO +12DB FILTERS TYPE PROPRIETARY 鼎OMBINING ISO CENTRE FREQUENCIES 30, 25HZ TO 20KHZ FREQUENCY TOLERANCE 5% MAXIMUM BOOST/CUT +/-12DB HIGH PASS FILTER 15HZ TO 300HZ, 12DB/OCTAVE LOW PASS FILTER 2K5HZ TO 30KHZ, 12DB/OCTAVE POWER REQUIREMENTS AC VOLTAGE 115/230 +/-12%, 50/60HZ CONSUMPTION <15VA DC VOLTAGE 24V +/-12% DC CONSUMPTION <250MA WEIGHT NETT 2.5KG SHIPPING 4KG DIMENSIONS WIDTH 482MM (19 INCHES) HEIGHT 45MM (1 3/4 INCHES) DEPTH 210MM (8 1/4 INCHES) TERMINATIONS INPUTS 3 PIN XLR OUTPUTS 3 PIN XLR AC POWER 3 PIN IEC DC POWER 2X4MM 釘ANANA TYPE

SOUNDBROKER IS AN AUTHORIZED RESELLER OF KLARK TEKNIK
